Schlage F93ADD, Addison Dummy Handleset
The traditional design of Schlage's Addison handleset features a molded edged and square mounts. This product is just for looks. It does not lock or latch. It is most often used as a pull to match trim on the inactive side of a double door. It is crafted out of solid brass and features a very easy installation.
Dummy Cylinder Handleset: Just for looks, it is used on inactive doors and does not function. Does not latch or lock.
Also available matching:
Addison Single Cylinder Handleset
Features of the Schlage Addison Handleset:
- Outside Trim: Handlesets are solid forged brass; wrought brass trim rings with concealed security inserts.
- Inside Trim: are zinc-based plated to match finishes indicated.
- Easy installation.
- Will fit most standard door preparations.
Specifications of the Dummy Addison Handleset:
- Rage of Door Preparation: 4" to 5-1/2"
- Exterior Total Height: 18-1/8" (with 5-1/2" door prep)
- Exterior Total Projection: 3-3/16"
- Exterior Center to Center Grip Range: adjustable 8-3/8" to 9-7/8"
- Exterior Dummy Deadbolt Escutcheon Height: 3-1/2"
- Exterior Dummy Deadbolt Escutcheon Width: 3"
- Exterior Top Grip Escutcheon Width: 3"
- Exterior Grip Height: 12-7/16"
- Schlage Addison Exterior Handleset Specifications (PDF)
This handleset is customisable with a huge selection of interior trim knobs and levers and additional finish color options just contact us for all the options!
The inside trim will match the outside handleset's finish.
|
