Don-Jo
8 x 33 Store Door Push and Pull Handle Set
$148.29
$185.36Save $37.07/ unit
In Stock — Estimated Shipping 1–2 business days
Contractor or designer?
Volume pricing + dedicated account rep available
Free Shipping Orders $250+
30-Day Returns
Secure Checkout
Ships from Florida
The Don-Jo 1156147-33CTC-628 is a set of eight 8 x 33 Push and Pull Handle hardware for commercial storefront doors. Constructed from solid aluminum with a clear anodized finish, the set includes heavy duty 3/8" diameter screw mounting hardware.
The unit is designed for doors ranging from 1-1/2" to 2-1/4" thick. The pull mechanism features an 8" center-to-center (CTC) pull bar, while the push bar provides a 33" CTC push bar.
Also Available: 9" x 33" Push Bar Set - 10" x 33" Push Bar Set - 12" x 33" Push Bar Set.
Dimensions & Fit
Door Thickness
1-1/2" to 2-1/4" Thick Door
Material & Finish
Material
Solid Aluminum
Finish
Clear Anodized Aluminum
Other
Pull Diameter
1" (25 mm)
Pull Projection
3-1/4" (83 mm)
Pull Clearance
2-1/4" (57 mm)
Pull Offset for Mounting Point
4" (100 mm)
Pull Center to Center (CTC)
8" (203 mm)
Pull Total Length
9" (228 mm)
Push Bar Diameter
1" (25 mm)
Push Bar Projection
2-1/4" (57 mm)
Push Bar Clearance
1-1/4" (32 mm)
Push Bar Center to Center (CTC)
33" (838 mm)
Push Bar Total Length
34" (864 mm)
Questions about this product? Call 954-776-5340 or send us a message below.
