−20%
Omnia
Traditional Mortise Single Cylinder Deadbolt, Omnia 041
$292.00
$365.00Save $73.00/ unit
In Stock - Estimated Shipping 3-5 Business Days
Contractor or designer?
Volume pricing + dedicated account rep available
Free Shipping Orders $250+
30-Day Returns
Secure Checkout
Ships from Florida
The Omnia 041 is a Traditional Mortise Single Cylinder Deadbolt, featuring a solid brass exterior mortise lock cylinder and a traditional style interior turnpiece.
This lock is designed for mortise boxes requiring a 4" x 3"h x 7/8" case and supports door thicknesses from 1-3/4" to 3". It utilizes a Schlage "C" 5-pin keyway.
The package includes the cylinder, collar, thumbturn, mortise box assembly, faceplate, strike, and dust box.
Dimensions & Fit
Door Thickness
select 1-3/4" to 3"
Backset
2-3/4"
Other
Exterior Diameter
1-3/4"
Exterior Projection
1/4"
Interior Diameter
1-3/4"
Interior Projection
1-1/8"
Mortise Case
4" x 3"h x 7/8". Heavy weight steel. Zinc dichromate finish for corrosion resistance.
Door Stile
4-1/2" minimum required.
Deadbolt
Stainless steel 5/8" x 1-1/16" with a 1" throw.
Faceplate
1-1/8"w x 4-5/8"h from brass or stainless steel. Armored Front, Adjustable steel front.
Strike
1-1/8"w x 3-1/2"h from brass or stainless steel.
Case Springs
High carbon steel
Questions about this product? Call 954-776-5340 or send us a message below.
